XWDGM Hollow Shaft Magnetic Particle Clutch for Precision Tension Control (6Nm–400Nm)

Precision Hollow Shaft Magnetic particle clutch for Advanced Web Tension Control

The XWDGM Hollow Shaft Magnetic particle clutch is engineered for accurate torque transmission, stable slip performance, and precise tension regulation in modern converting machinery. Designed for demanding winding and unwinding applications, this industrial clutch provides smooth torque control across a wide operating range from 6Nm to 400Nm.

Widely used in slitting, rewinding, printing, laminating, coating, packaging, textile, film converting, and lithium battery production lines, the XWDGM Magnetic particle clutch helps manufacturers achieve superior roll quality, reduced material waste, and improved production efficiency.

For complete tension management, the clutch can be integrated with a

 [Magnetic Particle Brake] to create a highly responsive closed-loop tension control system. This combination ensures stable web handling and consistent roll formation throughout the entire production process.

When paired with a [Tension Control System], torque output automatically adjusts according to changing roll diameters, maintaining constant tension from start to finish.

Its fast response characteristics make it ideal for high-speed [Web Tension Control] applications involving:

• Plastic Film
• PET Film
• BOPP Film
• Aluminum Foil
• Copper Foil
• Paper
• Nonwoven Fabric
• Textile Materials
• Lithium Battery Electrode Materials
• Adhesive Labels
• Flexible Packaging Materials

For multi-roll slitting operations, the clutch is frequently combined with a

 [Differential Shaft] to ensure uniform winding tension across all finished rolls while minimizing wrinkles, telescoping, and edge defects.

To improve loading efficiency and reduce downtime, many manufacturers install the clutch together with an [Air Expanding Shaft] for rapid core clamping and roll changeover.

Customers seeking complete converting solutions can also explore our [Slitting Machine Solutions], integrating advanced tension control technologies for high-speed and high-precision production lines.

Key Features

Precise Torque Control

Provides highly linear torque output for accurate and repeatable tension regulation.

Hollow Shaft Structure

Direct shaft mounting design simplifies installation and reduces transmission complexity.

Wide Torque Range

Available from 6Nm to 400Nm to meet diverse industrial requirements.

Fast Dynamic Response

Rapid torque adjustment improves winding accuracy and production efficiency.

Stable Continuous Slip Operation

Maintains consistent web tension during winding, rewinding, and unwinding processes.

Long Service Life

Premium magnetic powder and optimized cooling design ensure reliable long-term operation.

Low Maintenance Cost

Robust construction reduces downtime and maintenance requirements.

Advantages of Hollow Shaft Design

The hollow shaft configuration offers several operational benefits:

• Direct shaft installation
• Compact equipment integration
• Improved transmission alignment
• Reduced vibration and noise
• Faster clutch engagement
• Lower mechanical wear
• Simplified maintenance
• Suitable for space-constrained machinery

Compared with conventional shaft-mounted clutch systems, hollow shaft Magnetic Particle Clutch provide easier installation and superior adaptability for modern converting equipment.

How Does a Hollow Shaft Magnetic Particle Clutch Work?

The clutch operates through electromagnetic excitation and magnetic powder transmission technology.

1. DC current energizes the excitation coil.
2. Magnetic powder becomes magnetized.
3. Magnetic chains form between input and output rotors.
4. Torque is transmitted proportionally to excitation current.
5. Stable tension is maintained throughout winding and unwinding operations.

Because transmitted torque is nearly proportional to input current, operators can achieve highly accurate web tension control even under varying roll diameters and machine speeds.

Typical Applications

The XWDGM Hollow Shaft Magnetic Particle Clutch is widely used in:

• Slitting Machines
• Rewinding Machines
• Unwinding Systems
• Printing Machines
• Packaging Machinery
• Laminating Machines
• Coating Lines
• Film Converting Equipment
• Paper Processing Systems
• Wire & Cable Winding Machines
• Textile Machinery
• Lithium Battery Manufacturing Equipment
• Flexible Packaging Production Lines

Technical Advantages

Premium Magnetic Powder

High-grade magnetic powder provides stable torque output and extended service life.

Enhanced Heat Dissipation

The hollow shaft structure improves airflow and cooling performance during continuous slip operation.

High Torque Accuracy

Delivers precise and repeatable torque control across the full operating range.

Industrial Reliability

Manufactured under ISO quality management standards for demanding industrial environments.

OEM Customization Available

Customized torque ranges, shaft diameters, mounting configurations, voltage options, and application-specific designs are available.
